However G-Tune might be able to replace TPA for you. TPA and G-Tune: It is not tested and will most likely not result into something good. You also can save the configuration in an alternative way (like hitting save button in the GUI, casting an eepromwrite with trimming, acc calibration etc.) You will see the results in the GUI - the tuning results will only be saved if you enable G-Tune mode while the copter is disarmed and G-Tune was used before when armed. G-Tune in Horizon or Level mode will just affect Yaw axis (if more than 3 motors…) Yaw tune is disabled in any copter with less than 4 motors (like tricopters). You can set a too high P for the axis as default in the GUI, when the copter starts shaking the wobbles will be detected and P tuned down (be careful with the strength setting though - see below). The easiest way to tune all axis at once is to do some air-jumps with the copter in Acro (RC centered and G-Tune activated… of course.). 450ms to let the axis settle and then start tuning that axis again. So if you just roll only pitch and yaw are tuned. The G-Tune is based on the gyro error so it is only active when you give no RC input (that would be an additional error). It will start tuning the wanted / possible axis (see below) in a predefined range (see below).Īfter activation you will probably notice nothing! That means G-Tune will not start shaking your copter, you will have to do it (or simply fly and let it work). When flying in Acro mode (yaw tune in other modes possible as well - see below) you can activate G-Tune with an AUX box (switch) while the copter is armed. The implementation you have here is quite different and just for adjusting the P values of ROLL/PITCH/YAW in Acro mode. The G-Tune functionality for Cleanflight is ported from the Harakiri firmware.

Buzzer port for audible warnings and notifications.The algorithm has been originally developed by Mohammad Hefny (.

I2C port always powered, perfect for external sensors or always-on OLED Screen.

Sonar support for precision low-altitude hold.

Battery monitoring ports for voltage and current.

Dedicated output for programmable LEDs - great for orientation, racing and night flying.

No external inverters required (built-in).

Supports SBus, SumH, SumD, Spektrum1024/2048, XBus, PPM, PWM receivers.

#Xracer f303v.1 cleanflight firmware full#

Full support for OneShot ESCs for easy PID tuning and a sharper response.

Developer friendly debugging port (SWD) and boot mode selection, unbrickable bootloader.

Loop times up to ~2x as fast as previous-generation STM32F1 based boards.

The SPRacingF3 has an ARM Cortex-M4 72Mhz CPU with Math co-processor (FPU) for efficient flight calculations that gets more done in less time.

On-board high-capacity black box flight log recorder - optimize your tuning and see the results of your setup without guesswork.

The SPRacingF3 has a standard 36x36mm form-factor with 30.5mm mounting holes and weighs just 6 grams.

The SPRacingF3 runs Cleanflight which can be configured to suit your needs using a cross-platform GUI (Windows/OSX/Linux).

Connect your OSD + SmartPort + SBus + GPS + LED Strip + Battery Monitoring + Sonar + 8 motors - all at the same time!

Use all the features all the time e.g.

The SPRacingF3 builds on tried and tested software, processor and sensor technology to make your aircraft fly like it's on rails.

1x 4pin JST-SH socket for SWD debugging.

1x 2pin though-holes for pin headers for buzzer.

1x 2pin though-holes for pin headers for battery voltage.

#Xracer f303v.1 cleanflight firmware serial#

2x 4pin though-holes for pin headers for 2x serial ports.

8x 3pin though-holes for pin headers for ESC/Servo connections.

2x 8pin JST-SH sockets (PPM, PWM, SERIAL RX, GPIO, ADC, 3V, 5V, GND).

36x36mm board with 30.5mm mounting holes.

The hardware was designed by the lead developer of Cleanflight to be more capable than the previous-generation STM32F1-based boards after hearing feedback from the Cleanflight users, contributors and top-pilots.

#Xracer f303v.1 cleanflight firmware professional#

Professional - Symmetrical, Neat and Tidy.

Configurable - Choose to use connectors, solder pads or pins.

Practical - Easy to access connectors and solder pads.

#Xracer f303v.1 cleanflight firmware manual#

No more out-of-date wiki pages and second-hand information.ĭownload the SPRacingF3 Manual here. Being open-source means that you too can contribute to the system.Ĭleanflight comes with a detailed manual that is reviewed and maintained by the Cleanflight developers and community.

#Xracer f303v.1 cleanflight firmware software#

The SPRacingF3 runs the open-source Cleanflight flight control (FC) software which has an ever-growing community of friendly developers and users. Supports a variety of aircraft, tricopters, quadcopters, hexacopters, octocopters, planes and more. The SPRacingF3 gives you all the features you need for the heart of your aircraft, whether you're into FPV racing, acrobatic flying or aerial photography it's perfect.
